Brass Tube Plugs, Brass Tapered Tube Plugs & Industrial Tube Sealing Components Supplier in Mumbai, India
Unifit Metal Alloys is a manufacturer and supplier of Brass Tube Plugs, offering practical tube sealing components for heat-transfer equipment and various industrial applications. Brass is widely selected for tube applications because of its good machinability, strength, thermal conductivity and resistance to corrosion. These properties allow brass tube plugs to be used in equipment where reliable sealing and easy fabrication are important.
Our Brass Tube Plugs are available in different sizes, shapes and configurations to suit a wide range of tube sealing requirements. We can supply plugs according to tube diameter, wall thickness and equipment specifications. Different designs are available for maintenance, replacement and general industrial tube closure applications.
Brass Tube Plugs, Brass Tapered Tube Plugs & Industrial Tube Sealing Components Manufacturer and Supplier in Mumbai, India
The product range includes Brass Tapered Tube Plugs, Brass Threaded Tube Plugs, Brass Pin Tube Plugs, Brass Collar Tube Plugs, Brass Expandable Tube Plugs, Brass One-Piece Tube Plugs, Brass Boiler Tube Plugs, Brass Condenser Tube Plugs and Brass Heat Exchanger Tube Plugs. Customized dimensions can also be supplied according to customer requirements.
Brass Tube Plugs are used in heat exchangers, condensers, boilers, refrigeration equipment, HVAC systems, plumbing installations, industrial cooling systems and other heat-transfer applications. Their combination of mechanical strength, corrosion resistance and good thermal conductivity makes them suitable for different operating environments. At Unifit Metal Alloys, we provide Brass Tube Plugs in standard and customized specifications. Products can be supplied in different lengths, diameters, thread configurations and finishes based on the intended application. We can also accommodate specific requirements provided through technical drawings or equipment dimensions.
Get the Best Quote for Brass Tube Plugs. We Stock Brass Tube Plugs in Various Sizes, Dimensions and Specifications. Contact Us Today for a Competitive Quote.
Material Specification Chart Of Brass Tube Plug
| Specifications | ||||||
|---|---|---|---|---|---|---|
| Tube Size | 0.375″ to 3.000″ (9.5 – 76.2mm) OD | |||||
| Maximum Pressure | 150 PSI | |||||
| Length | Max 6 in 152.4 mm | |||||
Brass Tube Plug Sizes
| Metal Tapered Tube Plugs – Tube Plug Sizing Chart | ||||
|---|---|---|---|---|
| Tube OD | Gauge | Dimension (Inches) | ||
| “A” | “B” | “L” | ||
| Small End | Large End | Length | ||
| 1/4″ | 18-24 | 0.141″ | 0.235″ | 1-1/4″ |
| 3/8″ | 12-24 | |||
| 3/8″ | 15-24 | 0.213″ | 0.371″ | 1-3/4″ |
| 1/2″ | 13-15 | |||
| 1/2″ | 15-24 | 0.337″ | 0.495″ | |
| 5/8″ | 12-14 | |||
| 5/8″ | 14-24 | 0.449″ | 0.625″ | |
| 3/4″ | 10-14 | |||
| 3/4″ | 14-24 | 0.564″ | 0.750″ | |
| 7/8″ | 10-13 | |||
| 1″ | 8-9 | |||
| 7/8″ | 15-24 | 0.706″ | 0.875″ | |
| 1″ | 10-15 | |||
| 1″ | 13-18 | 0.776″ | 0.934″ | |
| 1″ | 18-24 | 0.892″ | 1.050″ | |
| 1-1/8″ | 13-17 | |||
| 1-1/8″ | 15-24 | 0.949″ | 1.125″ | 2″ |
| 1-1/4″ | 10-14 | |||
| 1-1/4″ | 13-19 | 1.010″ | 1.186″ | |
| 1-1/4″ | 19-24 | 1.147″ | 1.323″ | |
| 1-1/2″ | 10-24 | 1.200″ | 1.495″ | 3″ |
| 1-1/2″ | 14-24 | 1.305″ | 1.600″ | |
| 1-3/4″ | 6-13 | |||
| 1-3/4″ | 14-22 | 1.575″ | 1.870″ | |
| 2″ | 6-13 | |||
| 2″ | 12-22 | 1.700″ | 1.995″ | |
| 2-1/4″ | 6-13 | 1.805″ | 2.100″ | |
| 2-1/2″ | 5-18 | 2.000″ | 2.375″ | |
| 2-3/4″ | 4-10 | 2.232″ | 2.500″ | |
| 3″ | 5-12 | 2.524″ | 2.834″ | 4″ |
| 3″ | 10-23 | 2.625″ | 3.000″ | |
| 3-1/4″ | 7-14 | 2.875″ | 3.125″ | |
| 3-1/4″ | 13-23 | 3.010″ | 3.250″ | |
| 3-1/2″ | 7-12 | 3.125″ | 3.375″ | |
| 3-1/2″ | 13-23 | 3.260″ | 3.500″ | |
| 3-3/4″ | 5-12 | 3.274″ | 3.567″ | |
| 3-3/4″ | 13-23 | 3.510″ | 3.750″ | |
| 4″ | 5-12 | 3.524″ | 3.817″ | |
| 4″ | 13-23 | 3.782″ | 4.000″ | |
You need our support, to
have any projects?
Brass Threaded Tapered Plug Sizes
| Threaded Tapered Plugs | |||
|---|---|---|---|
| Max Hole Size | Part No. | Width | Hex Size |
| 0.350″ | TTP-375 | 0.365″ | 3/8″ |
| 0.450″ | TTP-500 | 0.480″ | 1/2″ |
| 0.580″ | TTP-625 | 0.615″ | 5/8″ |
| 0.710″ | TTP-750 | 0.730″ | 3/4″ |
| 0.835″ | TTP-875 | 0.855″ | 7/8″ |
| 0.950″ | TTP-1000 | 0.975″ | 1″ |
| 1.150″ | TTP-1125 | 1.100″ | 1 1/8″ |
| 1.200″ | TTP-1250 | 1.220″ | 1 1/4″ |
| 1.320″ | TTP-1375 | 1.345″ | 1 3/8″ |
| 1.450″ | TTP-1500 | 1.470″ | 1 1/2″ |
