Carbon Steel Header Plugs, Carbon Steel Shoulder Plugs & Industrial Heat Exchanger Sealing Components Supplier in Mumbai, India
Unifit Metal Alloys is a manufacturer and supplier of Carbon Steel Header Plugs / Shoulder Plugs in Mumbai, India. We offer header plugs in different sizes, dimensions and configurations for use in heat exchangers, air-cooled heat exchangers and other industrial heat-transfer equipment. Our products are selected to provide dependable tube isolation and secure closure during operation and maintenance.
Carbon Steel Header Plugs are designed to fit into the header box opposite individual tubes in heat exchanger assemblies. They provide convenient access for tube inspection, cleaning and maintenance while allowing individual tubes to be isolated when required. These plugs are particularly useful when a leaking or damaged tube needs to be taken out of service without affecting the complete heat exchanger.
Carbon Steel Header Plugs, Carbon Steel Shoulder Plugs & Industrial Heat Exchanger Sealing Components Manufacturer and Supplier in Mumbai, India
Carbon steel is widely used for header plug applications because of its good mechanical strength, machinability and suitability for many general industrial services. Depending on the operating conditions, the appropriate material grade, dimensions and surface finish can be selected to meet the requirements of the equipment. At Unifit Metal Alloys, Carbon Steel Header Plugs can be supplied in standard as well as customized sizes. We can accommodate requirements based on tube diameter, header box dimensions, plug design, gasket arrangement and technical drawings.
Our Carbon Steel Header Plugs / Shoulder Plugs are commonly used in heat exchangers, air-cooled heat exchangers, fin fan coolers, refineries, petrochemical plants, oil and gas facilities, power plants and chemical processing units. We focus on providing properly dimensioned and application-suitable header plugs for installation, replacement and routine maintenance requirements. Our range is suitable for customers looking for reliable tube closure and isolation components for industrial heat-transfer systems.
Get the Best Quote for Carbon Steel Header Plugs. We Stock Carbon Steel Header Plugs in Various Sizes, Dimensions and Specifications. Contact Us Today for a Competitive Quote.
Carbon Steel Header Plugs Specifications
| Specifications | ||||||
|---|---|---|---|---|---|---|
| Standard : | ASTM A105, A350 / ASME SA105, SA350 | |||||
| Diameter : | Min .375-9.525 , Max 2.5 in 63.5 mm | |||||
| Length : | Max 6 in 152.4 mm | |||||
| Maximum Pressure : | 150 PSI | |||||
Chemical Composition of Carbon Steel Header Plugs
| Element | Content |
|---|---|
| Carbon (C) | 0.30% – 0.60% |
| Manganese (Mn) | 0.60% – 1.35% |
| Phosphorus (P) | Max 0.035% |
| Sulfur (S) | Max 0.035% |
| Silicon (Si) | 0.10% – 0.60% |
| Chromium (Cr) | Max 0.30% |
| Nickel (Ni) | Max 0.40% |
| Copper (Cu) | Max 0.40% |
You need our support, to
have any projects?
Carbon Steel Header Plugs Mechanical Properties
| Property | Requirement |
|---|---|
| Tensile Strength | Minimum 485 MPa (70 ksi) |
| Yield Strength | Minimum 250 MPa (36 ksi) |
| Elongation (in 50 mm) | Minimum 22% |
| Reduction of Area | Minimum 30% |
| Hardness (Brinell, HBW) | 143 – 187 HB |
Ready Stock of Carbon Steel Header Plugs
Carbon Steel Header Plugs Application Industries
