Stainless Steel Plug Gaskets, Stainless Steel Heat Exchanger Plug Gaskets & Industrial Sealing Components Supplier in Mumbai, India
Unifit Metal Alloys is a manufacturer and supplier of Stainless Steel Plug Gaskets in Mumbai, India, providing precision sealing components for heat exchangers, header assemblies, pressure equipment and other industrial applications. Our plug gaskets are designed to provide dependable sealing performance where resistance to corrosion, pressure and temperature variations is required.
Stainless Steel Plug Gaskets are manufactured using carefully selected stainless steel materials that provide good mechanical strength, dimensional stability and resistance to corrosive service conditions. Their metallic construction makes them suitable for applications where conventional non-metallic sealing materials may not provide the required service performance.
Stainless Steel Plug Gasket, Stainless Steel Heat Exchanger Plug Gasket and Stainless Steel Industrial Sealing Gasket Manufacturer & Supplier in India
These gaskets are installed between plug components and their corresponding seating surfaces to help prevent leakage and maintain equipment integrity. Accurate dimensions and proper surface finish allow the gasket to seat correctly and provide consistent sealing during operation. At Unifit Metal Alloys, we supply Stainless Steel Plug Gaskets in different diameters, thicknesses and configurations. Standard sizes can be supplied for routine maintenance, while customized dimensions are available according to customer drawings, equipment specifications and plug requirements.
Our Stainless Steel Plug Gaskets are used in heat exchangers, condensers, boilers, pressure vessels, refineries, petrochemical plants, chemical-processing units, oil and gas facilities and power-generation equipment. We cater to replacement, maintenance and new-project requirements, with material grades and dimensional specifications selected according to the intended application. Customized gasket designs can also be developed for specialized industrial equipment.
Get the Best Quote for Stainless Steel Plug Gaskets. We Stock Stainless Steel Plug Gaskets in Various Sizes, Dimensions and Specifications. Contact Us Today for a Competitive Quote.
Stainless Steel Plug Gasket Specifications
| Characteristic | Specification Details |
|---|---|
| Material Grades | Stainless Steel 304, 304L, 316, 316L, UNS S30400, UNS S30403, UNS S31600, UNS S31603 |
| Gasket Type | Stainless Steel Plug Gasket |
| Size Range | Standard and custom sizes available |
| Pressure Rating | Custom-engineered to meet project requirements and applicable standards |
| Temperature Range | Suitable for high-temperature and high-pressure applications, depending on material grade and service conditions |
| Application | Heat Exchangers, Boilers, Condensers, Pressure Vessels and Industrial Piping Systems |
Standard Sizes of Stainless Steel Plug Gasket
| Plug Size | Outside Diameter (OD) | Inside Diameter (ID) | Thickness |
|---|---|---|---|
| 1/4″ | 0.500″ | 0.250″ | 0.062″ |
| 3/8″ | 0.625″ | 0.375″ | 0.062″ |
| 1/2″ | 0.750″ | 0.500″ | 0.062″ |
| 3/4″ | 1.000″ | 0.750″ | 0.062″ |
| 1″ | 1.250″ | 1.000″ | 0.062″ |
| 1-1/4″ | 1.625″ | 1.250″ | 0.078″ |
| 1-1/2″ | 1.875″ | 1.500″ | 0.078″ |
| 2″ | 2.375″ | 2.000″ | 0.078″ |
You need our support, to
have any projects?
Stainless Steel Plug Gasket Equivalent Grades
| Grade / Material | ASTM / ASME |
|---|---|
| Stainless Steel 304 | ASTM A240 / ASME SA240 |
| UNS | S30400 |
| EN / DIN | 1.4301 / X5CrNi18-10 |
| Stainless Steel 304L | ASTM A240 / ASME SA240 |
| UNS | S30403 |
| EN / DIN | 1.4307 / X2CrNi18-9 |
| Stainless Steel 316 | ASTM A240 / ASME SA240 |
| UNS | S31600 |
| EN / DIN | 1.4401 / X5CrNiMo17-12-2 |
| Stainless Steel 316L | ASTM A240 / ASME SA240 |
| UNS | S31603 |
| EN / DIN | 1.4404 / X2CrNiMo17-12-2 |
Ready Stock of Stainless Steel Plug Gasket
Stainless Steel Plug Gasket Application Industries
