Carbon Steel SA179 Tube Plugs, SA179 Tapered Tube Plugs & Industrial Tube Sealing Components Supplier in Mumbai, India
Unifit Metal Alloys is a manufacturer and supplier of Carbon Steel SA179 Tube Plugs, offering dependable tube sealing solutions for heat exchangers, boilers, condensers and other industrial equipment. Our SA179 Tube Plugs are supplied in different sizes, designs and configurations to meet the requirements of various maintenance, fabrication and repair applications.
SA179 Carbon Steel Tube Plugs are manufactured from suitable carbon steel material and are commonly selected for applications involving heat transfer equipment. They are used to seal or isolate individual tubes, helping prevent leakage and allowing damaged or unused tubes to be taken out of service without replacing the complete equipment. We can supply tube plugs according to required dimensions, tube sizes and application conditions.
Carbon Steel SA179 Tube Plugs, SA179 Tapered Tube Plugs & Industrial Tube Sealing Components Manufacturer and Supplier in Mumbai, India
Our range includes SA179 Tapered Tube Plugs, SA179 Threaded Tube Plugs, SA179 Pin Tube Plugs, SA179 One-Piece Tube Plugs, SA179 Boiler Tube Plugs, SA179 Condenser Tube Plugs and SA179 Heat Exchanger Tube Plugs. Different designs can be supplied depending on the method of installation and the specific sealing requirement.
Carbon Steel SA179 Tube Plugs are widely used in boilers, heat exchangers, condensers, power-generation equipment, petrochemical plants, chemical processing units and industrial heating systems. Their practical design makes them useful for tube isolation during maintenance, pressure testing and equipment repair. At Unifit Metal Alloys, we supply SA179 Tube Plugs in standard as well as customized dimensions. Products can be provided according to customer drawings, tube dimensions and technical specifications. We focus on maintaining proper dimensional accuracy and suitable material selection for each application.
Get the Best Quote for Carbon Steel SA179 Tube Plugs. We Stock SA179 Tube Plugs in Various Sizes, Dimensions and Specifications. Contact Us Today for a Competitive Quote.
Carbon Steel SA179 Tube Plugs Specifications
| Specifications | ||||||
|---|---|---|---|---|---|---|
| Standard : | ASTM A179 / ASME SA179 | |||||
| Diameter : | Min .375-9.525 , Max 2.5 in 63.5 mm | |||||
| Length : | Max 6 in 152.4 mm | |||||
| Maximum Pressure : | 150 PSI | |||||
Carbon Steel SA179 Tube Plugs Dimension Chart
| Metal Tapered Tube Plugs – Tube Plug Sizing Chart | ||||
|---|---|---|---|---|
| Tube OD | Gauge | Dimension (Inches) | ||
| “A” | “B” | “L” | ||
| Small End | Large End | Length | ||
| 1/4″ | 18-24 | 0.141″ | 0.235″ | 1-1/4″ |
| 3/8″ | 12-24 | |||
| 3/8″ | 15-24 | 0.213″ | 0.371″ | 1-3/4″ |
| 1/2″ | 13-15 | |||
| 1/2″ | 15-24 | 0.337″ | 0.495″ | |
| 5/8″ | 12-14 | |||
| 5/8″ | 14-24 | 0.449″ | 0.625″ | |
| 3/4″ | 10-14 | |||
| 3/4″ | 14-24 | 0.564″ | 0.750″ | |
| 7/8″ | 10-13 | |||
| 1″ | 8-9 | |||
| 7/8″ | 15-24 | 0.706″ | 0.875″ | |
| 1″ | 10-15 | |||
| 1″ | 13-18 | 0.776″ | 0.934″ | |
| 1″ | 18-24 | 0.892″ | 1.050″ | |
| 1-1/8″ | 13-17 | |||
| 1-1/8″ | 15-24 | 0.949″ | 1.125″ | 2″ |
| 1-1/4″ | 10-14 | |||
| 1-1/4″ | 13-19 | 1.010″ | 1.186″ | |
| 1-1/4″ | 19-24 | 1.147″ | 1.323″ | |
| 1-1/2″ | 10-24 | 1.200″ | 1.495″ | 3″ |
| 1-1/2″ | 14-24 | 1.305″ | 1.600″ | |
| 1-3/4″ | 6-13 | |||
| 1-3/4″ | 14-22 | 1.575″ | 1.870″ | |
| 2″ | 6-13 | |||
| 2″ | 12-22 | 1.700″ | 1.995″ | |
| 2-1/4″ | 6-13 | 1.805″ | 2.100″ | |
| 2-1/2″ | 5-18 | 2.000″ | 2.375″ | |
| 2-3/4″ | 4-10 | 2.232″ | 2.500″ | |
| 3″ | 5-12 | 2.524″ | 2.834″ | 4″ |
| 3″ | 10-23 | 2.625″ | 3.000″ | |
| 3-1/4″ | 7-14 | 2.875″ | 3.125″ | |
| 3-1/4″ | 13-23 | 3.010″ | 3.250″ | |
| 3-1/2″ | 7-12 | 3.125″ | 3.375″ | |
| 3-1/2″ | 13-23 | 3.260″ | 3.500″ | |
| 3-3/4″ | 5-12 | 3.274″ | 3.567″ | |
| 3-3/4″ | 13-23 | 3.510″ | 3.750″ | |
| 4″ | 5-12 | 3.524″ | 3.817″ | |
| 4″ | 13-23 | 3.782″ | 4.000″ | |
You need our support, to
have any projects?
Carbon Steel SA179 Tube Plugs Chemical Composition
| Element | SA 179 |
|---|---|
| C, % | 0.06-0.18 |
| Mn, % | 0.27-0.63 |
| P, % | 0.035 max |
| S, % | 0.035 max |
Ready Stock of Carbon Steel SA179 Tube Plugs
Carbon Steel SA179 Tube Plugs Application Industries
