Hastelloy Round Bar

Hastelloy Round Bars, Hastelloy Alloy Round Bars & Industrial Hastelloy Round Bars Supplier in Mumbai, India

Unifit Metal Alloys is a manufacturer, supplier and exporter of Hastelloy Round Bars in Mumbai, India, supplying nickel-based alloy bars for demanding industrial and engineering applications. Our Hastelloy Round Bars are available in different grades, sizes, diameters, lengths and surface finishes to meet standard as well as customized requirements.

We offer Hastelloy grades such as Hastelloy C276 selected for applications where excellent resistance to corrosion, chemical attack and harsh operating environments is required. These materials provide dependable mechanical performance in challenging process conditions.

Hastelloy Round Bar, Hastelloy Steel Round Bar and Hastelloy Alloy Round Bar Manufacturer & Supplier in India

Our Hastelloy Round Bars can be supplied in various forms and finishes, including bright, polished, ground and machined surfaces. Standard stock sizes are available for quick requirements, while cut-to-length bars and customized dimensions can be supplied according to customer drawings and specifications.

Hastelloy Round Bars are widely used in chemical processing, petrochemical, pollution control, power generation, oil and gas, marine, pharmaceutical and industrial equipment manufacturing where resistance to aggressive chemicals and corrosive media is essential. At Unifit Metal Alloys, we focus on material conformity, dimensional accuracy and surface quality during order processing. Material Test Certificates and relevant inspection documents can also be provided according to customer requirements.

Get the Best Quote for Hastelloy Round Bars. We Stock Hastelloy Round Bars in Various Diameters, Lengths, Sizes and Material Specifications. Contact Us Today for a Competitive Quote.

Specifications of Hastelloy Round Bar

Feature Specification Details
Round Bar Sizes Diameter: 3 – 600 mm | Length: 0.5 – 6.0 m (Custom sizes available)
Hex Bar Sizes Diameter: 3 – 180 mm | Length: 0.5 – 6.0 m (Available cut to size)
Flat Bar Sizes Thickness: 0.5 – 200 mm | Width: 1.5 – 250 mm | Length: 0.5 – 6.0 m
Square Bar Sizes Side Width: 2 – 200 mm | Length: 0.5 – 6.0 m (Available cut to length)
Standard Shapes Round, Square, Hex, Flat, and Rectangular
Material Standards ASTM B574, ASME SB574
Supply Conditions Annealed (ANN), Hardened & Tempered (H&T), Precipitation Hardened (PH), Turned, or Rough
Manufacturing Technique Hot Rolled, Cold Rolled, or Forged
Surface Finish Polished, Black, Bright, or Pickled
Dimensional Tolerances H8 to H13, K9 to K12, or Custom
Key Benefits High Strength, Weldability, Versatile Applications, and Extended Service Life
Testing Methods Chemical, Mechanical, PMI (Positive Material Identification), and Flaring tests
Material Origin American, European, Russian, Japanese, or Korean
Packaging Options Bubble wraps, Wooden Pallets, Shear Box, Bundle, or Custom

Hastelloy Round Bar Chemical Composition

Grades Cr P ≤ Mo S ≤ C ≤ Co ≤ Mn ≤ Si ≤ Fe
C276 14.5–16.5 0.04 15.0–17.0 0.03 0.01 2.5 1.0 0.08 4.0–7.0
C22 20.0–22.5 0.02 12.5–14.5 0.02 0.015 2.5 0.5 0.08 3.0–6.0
B3 1.0–3.0 0.03 27.0–32.0 0.01 0.01 3.0 3.0 0.10 1.0–3.0
B2 1.0 max 0.04 26.0–30.0 0.03 0.02 1.0 1.0 0.10 2.0 max
X 20.5–23.0 0.04 8.0–10.0 0.03 0.05–0.15 0.5–2.5 1.0 1.0 17.0–20.0
C2000 22.0–24.0 0.025 15.0–17.0 0.01 0.01 2.0 0.5 0.08 3.0 max

You need our support, to
have any projects?

Get Free Quotes
Contact Us

Hastelloy Round Bar Mechanical Properties

Grade Yield Strength (0.2% Offset) Tensile Strength Elongation Melting Point Density
C276 115,000 psi (790 MPa) 52,000 psi (355 MPa) 40% 1370°C (2500°F) 8.89 g/cm³
C22 100,000 psi (690 MPa) 45,000 psi (310 MPa) 45% 1399°C (2550°F) 8.69 g/cm³
Hybrid BC1 725 MPa 310 MPa 40% 1343–1443°C 8.83 g/cm³
C4 783 MPa 365 MPa 55% 1350–1400°C 8.64 g/cm³
B3 115,000 psi (760 MPa) 52,000 psi (350 MPa) 40% 1370°C (2550°F) 9.2 g/cm³
B2 115,000 psi (760 MPa) 52,000 psi (350 MPa) 40% 1370°C (2550°F) 9.2 g/cm³
X 655 MPa 240 MPa 35% 1355°C 8.22 g/cm³

Ready Stock of Hastelloy Round Bar

Hastelloy C276 Round Bars
Hastelloy C22 Round Bars
Hastelloy B2 Round Bars
Hastelloy Alloy Round Bars
Hastelloy Forged Round Bars
Hastelloy Precision Round Bars
Hastelloy Ground Round Bars
Hastelloy Bright Round Bars
Hastelloy Hot Rolled Round Bars
Hastelloy Cold Drawn Round Bars
Hastelloy Machined Round Bars
Hastelloy Annealed Round Bars

Hastelloy Round Bar Application Industries

Refineries
90%
Oil and Gas Industry
96%
Power Generation
80%
Pharmaceutical Equipment
85%
Pulp & Paper Industry
88%
