Stainless Steel Round Bar

Stainless Steel Round Bars, Stainless Steel Round Bar Stock & Industrial Stainless Steel Round Bars Supplier in Mumbai, India

Unifit Metal Alloys is a manufacturer, supplier, stockist and exporter of Stainless Steel Round Bars in Mumbai, India, supplying stainless steel products for engineering, fabrication and industrial applications. We offer round bars in a wide range of grades, diameters, lengths and finishes to meet both standard and customized requirements.

Stainless Steel Round Bars are manufactured from corrosion-resistant steel alloys containing chromium along with other alloying elements. Their combination of strength, durability, surface stability and resistance to rust and corrosive environments makes them suitable for a wide variety of industrial components.

Stainless Steel Round Bar, Stainless Steel Round Bar Stock and Industrial Stainless Steel Round Bar Manufacturer & Supplier in India

We supply Stainless Steel Round Bars in different grades and sizes, with options such as forged, hot rolled, cold drawn, ground, bright, polished and machined finishes. Cut-to-length and customized dimensions can also be supplied according to customer drawings and technical specifications.

These round bars are commonly used in chemical processing, food processing, pharmaceutical equipment, petrochemical plants, oil and gas, construction, marine applications, power generation and general engineering. They are suitable for manufacturing shafts, fasteners, valves, fittings, machined components and structural parts. At Unifit Metal Alloys, we focus on material grade, dimensional accuracy, surface finish and overall product quality. Material Test Certificates and inspection documentation can be supplied with orders as required.

Get the Best Quote for Stainless Steel Round Bars. We Stock Stainless Steel Round Bars in Various Diameters, Lengths, Sizes and Material Specifications. Contact Us Today for a Competitive Quote.

Specifications of Stainless Steel Round Bar

Specifications
Stainless Steel Bar Length 2 to 6 meters or 8 to 20 feet
SS Rod Chamfering Available in 30, 45 & 60 degree thru fully automatic both-end chamfering machine
Ultrasonic Test of ASTM A276 Threaded Rod As per ASTM A-388, EN 10308 (class 1 to 4), API 6A/ISO it is 100% tested thru Digital Ultrasonic Flaw Detector, 10423:2003-PSL 3, MIL STD 2154, SEP 1920:1984
SS Round Bar Size Tolerances h11
Tolerance of Cold Rolled SS Round Bar Length Stock in special cut to length bar in tolerance – 0/+10mm (-0 +0.5 inch)
Surface Finish of Cold Rolled SS Bar Cold drawn or Belt polished condition
Bar Heat Treatment Annealed and Solution Annealed

Stainless Steel Round Bar Weight Chart


DiameterWeight ChartDiaWeight Chart
(mm)per metre (kg)(in)per metre (kg)
3mm0.061/8″0.06
4mm0.103/16″0.14
5mm0.161/4″0.25
6mm0.225/16″0.39
7mm0.303/8″0.56
8mm0.407/16″0.77
10mm0.621/2″1.00
12mm0.899/16″1.22
14mm1.225/8″1.56
15mm1.4011/16″1.89
16mm1.593/4″2.25
18mm2.017/8″3.07
20mm2.481″4.03
22mm3.00
24mm3.57
25mm3.88

You need our support, to
have any projects?

Get Free Quotes
Contact Us

Stainless Steel Round Bar Dimension Chart

Dimension Chart
Diameter or Width (mm) Weight per meter Sectional Area Perimeter
Square (kg) Round (kg) Square (cm²) Round (cm²) Square (cm) Round (cm)
5.0 0.20 0.15 0.25 0.20 2.0 1.57
5.5 0.24 0.19 0.30 0.24 2.2 1.78
6.0 0.28 0.22 0.36 0.28 2.4 1.88
7.0 0.38 0.30 0.49 0.38 2.8 2.20
8.0 0.50 0.39 0.64 0.50 3.2 2.51
9.0 0.64 0.50 0.81 0.64 3.6 2.83
10 0.73 0.63 1.00 0.79 4.0 3.14
11 0.95 0.75 1.21 0.95 4.4 3.46
12 1.13 0.89 1.44 1.13 4.8 3.77
14 1.54 1.21 1.96 1.54 5.6 4.40
16 2.01 1.58 2.56 2.01 6.4 5.03
18 2.54 2.00 3.24 2.54 7.2 5.65
20 3.14 2.47 4.00 3.14 8.0 6.28
22 3.80 2.98 4.84 3.80 8.8 6.91
25 4.91 3.85 6.25 4.91 10.0 7.85
28 6.15 4.83 7.84 6.16 11.2 8.80
32 8.04 6.31 10.24 8.04 12.8 10.05
36 10.17 7.99 12.96 10.18 14.4 11.31
40 12.56 9.86 16.00 12.57 16.0 12.57
45 15.90 12.49 20.25 15.90 18.0 14.14
50 19.62 15.41 25.00 19.64 20.0 15.71
56 24.62 19.34 31.36 24.63 22.4 17.59
63 31.16 24.47 36.69 31.17 25.2 19.79
71 39.57 31.08 50.41 39.59 28.4 22.31
80 50.24 39.46 64.00 50.27 32.0 25.13

Ready Stock of Stainless Steel Round Bar

Stainless Steel 304 Round Bars
Stainless Steel 304L Round Bars
Stainless Steel 316 Round Bars
Stainless Steel 316L Round Bars
Stainless Steel 321 Round Bars
Stainless Steel 347 Round Bars
Stainless Steel 410 Round Bars
Stainless Steel 420 Round Bars
Stainless Steel 430 Round Bars
Stainless Steel Forged Round Bars
Stainless Steel Precision Round Bars
Stainless Steel Ground Round Bars

Stainless Steel Round Bar Application Industries

Refineries
90%
Oil and Gas Industry
96%
Power Generation
80%
Pharmaceutical Equipment
85%
Pulp & Paper Industry
88%
